Models
Drive type
Gear
Emission
Models Gasoline Models Diesel Models
Standard Wheelbase Long Wheelbase Standard Wheelbase Long Wheelbase
ZN1023U5N5 ZN1023U5N5B ZN1033UCN5 ZN1033UCN5B ZN1024U5N5 ZN1034UCN5 ZN1033U5X5 ZN1033UCX5 ZN1034U5X5 ZN1034UCX5
Standard Luxury Standard Luxury Standard Luxury Standard Luxury Standard Luxury Standard Luxury Standard Luxury Standard Luxury
Drive type 2WD 4WD 2WD 4WD 2WD 4WD 2WD 4WD
Gear 5MT 5MT 6MT 6MT
Emission EuroV EuroV EuroV EuroV EuroV EuroV EuroV EuroV
Models
Drive type
Gear
Emission
L x W x H (mm)
Wheel base (mm)
Track (front/rear)
Cargo L x W x H (mm)
Ground clearance
Min. turning radius
G.V.W., (kg)
Curb weight (kg)
Load capacity (kg)
Approach angle/ Departure angle (°)
Max. grade ability (%)
Passenger number
Fuel tank (L)
Max. speed (km/h)
Engine Type
Displacement(L)
Max. power (kw/rpm)
Max. torque (Nm/rpm)
Driving system Braking system
Suspension system
Tire
Comfort Central lock
Remote key
Power windows, 4door
Intermittent wiper
FM/AM + USB
7-inch-screen MP5 (with Bluetooth/ Reverse image/Mobile phone interconnection)
Power Air conditioner
Power exterior mirrors (with turning lamps)
Auto-dimming interior mirror
Sun visor (make-up mirror, front passenger side)
Information display
Built-in antenna
Height-adjustable driver seat
Angle-adjustable steering wheel
Multifunctional steering wheel
Cloth seats (black)
Leather seats, door trim (two-tone)
Safety Air bag, driver side
Air bag, front passenger side
Seatbelt warning and door warning
Seatbelts on second row
Reversing sensor
Tire pressure monitoring
Electric adjustable headlights
Rear fog lamp
Front fog lamp
High-mount braking lamp
ABS+EBD
ESP
Guardrail protective rack
New-look protective rack (with rope hook)
Pipe-type protective rack
Interior Black interior (hard-plastic dashboard)
Bicolor interior (soft-roll dashboard)
Options Reflective vest
Outside rope hook
Inside rope hook
Rear cargo protector
Side step pedal
Baggage rack
Daytime running light
Models Gasoline Models Diesel Models
Standard Wheelbase Long Wheelbase Standard Wheelbase Long Wheelbase
ZN1023U5N5 ZN1023U5N5B ZN1033UCN5 ZN1033UCN5B ZN1024U5N5 ZN1034UCN5 ZN1033U5X5 ZN1033UCX5 ZN1034U5X5 ZN1034UCX5
Standard Luxury Standard Luxury Standard Luxury Standard Luxury Standard Luxury Standard Luxury Standard Luxury Standard Luxury
Drive type 2WD 4WD 2WD 4WD 2WD 4WD 2WD 4WD
Gear 5MT 5MT 6MT 6MT
Emission EuroV EuroV EuroV EuroV EuroV EuroV EuroV EuroV
L x W x H (mm) 5095×1720×1680/1760 5095×1720×1693/1760 5095×1820×1715/1795 5095×1820×1728/1795 5410×1820×1725/1805 5410×1820×1738/1805 5410×1820×1725/1805 5410×1820×1738/1805 5095×1820×1725/1805 5095×1820×1738/1805 5095×1820×1725/1805 5095×1820×1738/1805 5410×1820×1725/1805 5410×1820×1738/1805 5410×1820×1725/1805 5410×1820×1738/1805
Wheel base (mm) 3050 3050 3365 3365 3050 3050 3365 3365
Track (front/rear) 1415/1410 1545/1525 1525/1505 1525/1505 1525/1505 1525/1505 1525/1505 1525/1505
Cargo L x W x H (mm) 1395×1390×430 1395×1390×430 1710×1390×430 1710×1390×430 1395×1390×430 1395×1390×430 1710×1390×430 1710×1390×430
Ground clearance 210 215 215 215 215 215 215 215
Min. turning radius 6.5 6.5 7 7 6.5 6.5 7 7
G.V.W., (kg) 2310 2510 2430 2560 2505 2605 2505 2605
Curb weight (kg) 1495 1695 1615 1745 1690 1790 1740 1840
Load capacity (kg) 490 490 490 490
Approach angle/ Departure angle (°) 28/20 30/20 30/20 30/20 30/20
Max. grade ability (%) 30 40 30 40 40
Passenger number 5 5 5 5
Fuel tank (L) 60 60 60 60
Max. speed (km/h) 160 140 150 140
Engine Type ZG24 ZG24 ZD25T5 ZD25T5
Displacement(L) 2.438 2.438 2.498 2.498
Max. power (kw/rpm) 102/4600~5000 102/4600~5000 103/3800 103/3800
Max. torque (Nm/rpm) 217/2600~3200 217/2600~3200 305/1800~2600 305/1800~2600
Driving system Braking system Front Disc/Rear Drum Front Disc/Rear Drum Front Disc/Rear Drum Front Disc/Rear Drum
Suspension system Front suspension: double-wishbone, independent Front suspension: double-wishbone, independent Front suspension: double-wishbone, independent Front suspension: double-wishbone, independent
Rear suspension: steel spring Rear suspension: steel spring Rear suspension: steel spring Rear suspension: steel spring
Tire 215/75R15 245/70R16 245/70R16 245/70R16
Comfort Central lock
Remote key
Power windows, 4door
Intermittent wiper
FM/AM + USB - - - - - - - -
7-inch-screen MP5 (with Bluetooth/ Reverse image/Mobile phone interconnection) - - - - - - - -
Power Air conditioner
Power exterior mirrors (with turning lamps)
Auto-dimming interior mirror - - - - - - - -
Sun visor (make-up mirror, front passenger side)
Information display
Built-in antenna
Height-adjustable driver seat
Angle-adjustable steering wheel
Multifunctional steering wheel - - - - - - - -
Cloth seats (black) - - - - - - - -
Leather seats, door trim (two-tone)
Safety Air bag, driver side
Air bag, front passenger side - - - - - - - -
Seatbelt warning and door warning
Seatbelts on second row
Reversing sensor
Tire pressure monitoring - - - - - - - -
Electric adjustable headlights
Rear fog lamp
Front fog lamp
High-mount braking lamp
ABS+EBD
ESP - - - - - - - - - - - -
Guardrail protective rack - - - - - - - -
New-look protective rack (with rope hook) - - - - - - - -
Pipe-type protective rack
Interior Black interior (hard-plastic dashboard) - - - - - - - -
Bicolor interior (soft-roll dashboard) - - - - - - - -
Options Reflective vest
Outside rope hook
Inside rope hook
Rear cargo protector
Side step pedal
Baggage rack
Daytime running light - - - - - - - -
Note: “●” Standard “○” Optional “▬” Not available
All content of this brochure is only for reference. The manufacturer reserves the right to make any changes or stop manufacturing without notice in advance.
